1. Why GLinks Matter: The Deep Linking Revolution

In traditional web applications, deep linking is straightforward—you craft a URL with path segments and query parameters, and the server routes you to the right page. But GRIDNET OS isn’t a traditional web application. It’s a complete operating system that runs in your browser, with multiple windowed applications, user sessions, blockchain connections, and cryptographic authentication.

When someone shares a link to view a specific transaction, what actually needs to happen?

GLinks encapsulate all of this in a single URL. One click, and the entire orchestration happens automatically.

2. Anatomy of a GLink

A GLink is a URL that carries encoded instructions for GRIDNET OS. Let’s dissect its structure:

URL Structure

JSON Data Format

The encoded payload is a JSON object with the following structure:

Known Package IDs

3. The GLink Lifecycle

Understanding the complete lifecycle of a GLink is essential for both users and developers. From the moment a GLink URL is clicked to the final confirmation, here’s what happens:

4. Implementing GLink Support in Your UI dApp

Now that you understand how GLinks work conceptually, let’s build support into your own dApp. The process follows a clear pattern: detect → accept → process → confirm. Each step serves a specific purpose in ensuring a smooth user experience.

The most important thing to understand is why we structure things this way: the CGLinkHandler has strict timeouts (15 seconds initially, extending to 3 minutes after acceptance). If your dApp doesn’t respond in time, the GLink fails and the user sees an error. The pattern below ensures you always respond promptly while still having enough time to do complex operations.

Step 1: Import GLink Classes

You’ll need both classes: CGLink for creating GLinks programmatically (e.g., “Copy GLink to clipboard” buttons), and CGLinkHandler for responding to incoming GLinks:

import {
CGLink,
CGLinkHandler
} from '/lib/GLink.js';

Step 2: Detect and Accept GLink on Initialize

When your dApp starts, the first thing you need to check is: “Was I launched because of a GLink?” This check happens in your initialize() method, and the answer comes from inherited CWindow properties.

Critical: Call acceptGLink() as soon as you detect the GLink—this extends your timeout from 15 seconds to 3 minutes. Don’t wait until you’re ready to process; accept first, then take your time:

async initialize() {
// ... your normal initialization code ...
// Check if launched via GLink
if (this.wasLaunchedViaGLink) {
console.log('[MyApp] Detected launch via GLink');
// Get the GLink data passed to this dApp
const glinkData = this.getGLinkData;
// Accept immediately - this extends the timeout and shows progress
const glinkHandler = CGLinkHandler.getInstance();
glinkHandler.acceptGLink('MyApp initializing...');
// Process after a short delay to allow UI to stabilize
setTimeout(() => {
this.processGLink(glinkData);
}, 2000);
}
}

Step 3: Implement the processGLink Method

The processGLink() method is where the actual work happens. This is your dApp’s contract with the GLink system: you receive structured data (view, action, data) and you’re responsible for making something happen.

The pattern here is important: navigate first, then act. If the GLink specifies a view, switch to it before executing the action. This ensures your action has the right DOM context to work with. Always wrap everything in try/catch and always end with either confirmGLinkProcessed() or rejectGLink()—never leave the handler hanging.

/**
* Process GLink data - handle deep link navigation.
* This method is the heart of your GLink support.
* @param {Object} glinkData - The parsed GLink data {view, action, data}
*/
processGLink(glinkData) {
const glinkHandler = CGLinkHandler.getInstance();
if (!glinkData) {
glinkHandler.rejectGLink('No GLink data provided');
return;
}
// Accept the GLink (in case not already accepted)
glinkHandler.acceptGLink('Processing...');
const { view, action, data } = glinkData;
try {
// Step 1: Navigate to specified view (if any)
if (view) {
this.switchToView(view);
}
// Step 2: Execute action (if any)
if (action !== null && action !== undefined) {
this.executeGLinkAction(action, data);
}
// Step 3: Confirm success
glinkHandler.confirmGLinkProcessed('Action completed successfully');
} catch (error) {
console.error('[MyApp] GLink error:', error);
glinkHandler.rejectGLink(`Error: ${error.message}`);
}
}
/**
* Execute a specific GLink action
*/
executeGLinkAction(actionId, data) {
switch (actionId) {
case 1: // Example: View item details
this.viewItemDetails(data.itemId);
break;
case 2: // Example: Pre-fill form
this.prefillForm(data);
break;
default:
throw new Error(`Unknown action ID: ${actionId}`);
}
}

Step 4: Define Your Action IDs

Each dApp should define its own action constants as static properties:

// Define action constants for your dApp
static get GLinkActions() {
return {
VIEW_ITEM: 1,
PREFILL_FORM: 2,
SEARCH: 3,
NAVIGATE: 4
};
}

5. Case Study: Wallet UI dApp

The Wallet UI dApp presents an interesting implementation challenge: what happens when a GLink arrives but the wallet is PIN-locked? You can’t just ignore the GLink—the user clicked a payment link for a reason. But you also can’t process financial operations without the user first proving they have access to their wallet.

The Wallet solves this elegantly by accepting the GLink immediately (to extend the timeout and provide feedback), storing it for later, and then processing it once the user unlocks with their PIN. Let’s examine how this works in practice.

Wallet GLink Actions

The Wallet defines five actions, covering the primary user workflows: sending funds, receiving funds, viewing history, and managing keychains and settings.

Handling PIN-Locked State

Here’s where things get interesting. The CGLinkHandler has a 15-second timeout—if the dApp doesn’t respond, the GLink fails. But what if the user needs to enter their PIN first? That could easily take longer than 15 seconds.

The solution is a two-phase approach: accept immediately to extend the timeout to 3 minutes, then defer processing until the wallet is unlocked. The code stores the GLink data in a member variable and processes it after the PIN unlock callback fires:

// In initialize()
if (this.wasLaunchedViaGLink) {
const glinkHandler = CGLinkHandler.getInstance();
const glinkData = this.getGLinkData;
// Accept immediately to extend timeout
glinkHandler.acceptGLink('Wallet received GLink');
// Store for later processing
this.mPendingGLinkData = glinkData;
// Process immediately if not locked, otherwise wait for unlock
setTimeout(() => {
if (!this.mIsLocked && this.mPendingGLinkData) {
this.processGLink(this.mPendingGLinkData);
this.mPendingGLinkData = null;
}
}, 1000);
}
// In onPINUnlock() handler
if (this.mPendingGLinkData) {
console.log('[Wallet] Processing pending GLink after unlock...');
this.processGLink(this.mPendingGLinkData);
this.mPendingGLinkData = null;
}

Example: Payment Request GLink

// Create a GLink for a payment request
const paymentGLink = CGLink.create(
CGLink.PackageIDs.WALLET, // Target: Wallet dApp
'send', // View: Send tab
1, // Action: PREFILL_SEND
{
address: 'alice.grid', // Recipient address
amount: '100' // Amount in GNC
}
);
// Result: https://ui.gridnet.org/?glink=eyJhcHAiOiJvcmcuZ3JpZG5ldHByb2plY3QuVUlkQXBwcy53YWxsZXQiLCJ2aWV3Ijoic2VuZCIsImFjdGlvbiI6MSwiZGF0YSI6eyJhZGRyZXNzIjoiYWxpY2UuZ3JpZCIsImFtb3VudCI6IjEwMCJ9fQ

6. Case Study: Blockchain Explorer UI dApp

While the Wallet dealt with deferred processing (PIN unlock), the Blockchain Explorer faces a different challenge: asynchronous data loading. When you click a GLink to view a specific transaction, the Explorer needs to fetch that transaction from the blockchain before it can display it.

The Explorer’s approach is simpler than the Wallet’s because it doesn’t have a PIN gate. It accepts the GLink during initialization, waits a brief moment for the UI to stabilize, then processes the action. The key insight here is the use of a 2-second delay after accepting—this gives the Explorer’s data fetching mechanisms time to initialize without blocking the GLink timeout.

Explorer GLink Actions

The Explorer exposes four actions focused on blockchain data exploration:

Explorer processGLink Implementation

Notice how the Explorer’s implementation is more straightforward—it doesn’t need the deferred processing pattern because there’s no unlock step. It switches to the specified view (if any), then executes the action based on the numeric ID:

processGLink(glinkData) {
const glinkHandler = CGLinkHandler.getInstance();
if (!glinkData) {
glinkHandler.rejectGLink('No GLink data provided');
return;
}
glinkHandler.acceptGLink('Explorer processing...');
const { view, action, data } = glinkData;
try {
// Navigate to view if specified
if (view) {
this.ui.switchToSection(view);
}
// Execute action based on numeric ID
if (action !== null) {
switch (action) {
case 1: // VIEW_BLOCK
this.viewBlockDetails(data.blockId);
break;
case 2: // VIEW_TRANSACTION
this.viewTransactionDetails(data.txId);
break;
case 3: // VIEW_DOMAIN
this.searchDomain(data.domain);
break;
case 4: // SEARCH
this.performSearch(data.query);
break;
default:
glinkHandler.rejectGLink(`Unknown action: ${action}`);
return;
}
glinkHandler.confirmGLinkProcessed('Action completed');
} else if (view) {
glinkHandler.confirmGLinkProcessed('View opened');
} else {
glinkHandler.rejectGLink('No action or view specified');
}
} catch (error) {
glinkHandler.rejectGLink(`Error: ${error.message}`);
}
}

Creating Explorer GLinks

// View a specific transaction
const txGLink = CGLink.create(
CGLink.PackageIDs.EXPLORER,
'transactions',
2, // VIEW_TRANSACTION
{ txId: 'abc123...' }
);
// View a specific block
const blockGLink = CGLink.create(
CGLink.PackageIDs.EXPLORER,
'blocks',
1, // VIEW_BLOCK
{ blockId: '12345' }
);
// Search for a domain
const domainGLink = CGLink.create(
CGLink.PackageIDs.EXPLORER,
'search',
3, // VIEW_DOMAIN
{ domain: 'alice.grid' }
);

7. Creating GLinks Programmatically

So far we’ve talked about receiving and processing GLinks. But what about creating them? When a user wants to share a transaction, copy a payment request link, or generate a QR code for their wallet address, your dApp needs to create GLinks on the fly.

The CGLink class makes this trivial. The create() method handles all the JSON construction and URL-safe Base64 encoding automatically—you just provide the semantic data.

Basic Creation

The method signature is CGLink.create(appPackageID, view?, action?, data?). Only the first parameter is required; everything else is optional:

import { CGLink } from '/lib/GLink.js';
// Simplest GLink - just launch the app (no specific action)
const simpleLink = CGLink.create('org.myapp.MyDApp');
// With view - open app to a specific tab
const viewLink = CGLink.create('org.myapp.MyDApp', 'settings');
// With view and action - open tab and do something
const actionLink = CGLink.create('org.myapp.MyDApp', 'items', 1);
// Complete GLink with data - the most common case
const fullLink = CGLink.create(
'org.myapp.MyDApp',
'items',
1,
{ itemId: 'abc123', highlight: true }
);

Adding a “Copy GLink” Button

A common UX pattern is to let users copy a GLink to their clipboard so they can share it. The CGLink.copyToClipboard() method handles both modern and legacy browser APIs:

// Add a "Share" button to your UI
copyGLinkBtn.addEventListener('click', async () => {
// Generate a GLink for the current state
const glink = CGLink.create(
MyDApp.getPackageID(),
this.currentView,
MyDApp.GLinkActions.VIEW_CURRENT,
{ itemId: this.currentItemId }
);
// Copy to clipboard with fallback for older browsers
const success = await CGLink.copyToClipboard(glink);
if (success) {
this.showNotification('GLink copied! Share it anywhere.');
}
});

8. API Reference

This section provides a complete reference for all GLink-related APIs. Use this as your go-to documentation when implementing GLink support.

CGLink Class

The CGLink class is a static utility for creating and parsing GLinks. You never instantiate it—just call its static methods directly.

CGLinkHandler Class

The CGLinkHandler is a singleton that manages the GLink lifecycle at the system level. Your dApp interacts with it through its instance methods, primarily acceptGLink(), confirmGLinkProcessed(), and rejectGLink().

CWindow Properties (Inherited)

All UI dApps extend CWindow, which provides these GLink-related properties. You don’t need to do anything to get them—they’re automatically populated when your app is launched via GLink.

9. Best Practices

Over time, we’ve learned what works and what doesn’t when implementing GLink support. Here are the patterns that consistently lead to a great user experience:

10. The Encoding/Decoding Flow

You’ll rarely need to manually encode or decode GLinks—the CGLink class handles it for you. But when debugging a misbehaving GLink or when you want to construct one by hand for testing, understanding the encoding process is invaluable.

GLinks use URL-safe Base64, which is slightly different from standard Base64. The reason is simple: standard Base64 includes +, /, and = characters, which have special meaning in URLs. URL-safe Base64 replaces these with URL-friendly alternatives.

Manual Testing with Browser Console

// Encode a GLink manually (for testing)
const data = { app: 'org.gridnetproject.UIdApps.wallet', view: 'send' };
const json = JSON.stringify(data);
const utf8 = new TextEncoder().encode(json);
let binary = '';
utf8.forEach(b => binary += String.fromCharCode(b));
const base64 = btoa(binary).replace(/\+/g, '-').replace(/\//g, '_').replace(/=/g, '');
console.log(`https://ui.gridnet.org/?glink=${base64}`);
// Decode a GLink manually (for debugging)
const encoded = 'eyJhcHAiOiJ3YWxsZXQifQ';
let restored = encoded.replace(/-/g, '+').replace(/_/g, '/');
while (restored.length % 4) restored += '=';
const decoded = atob(restored);
const bytes = new Uint8Array(decoded.length);
for (let i = 0; i < decoded.length; i++) bytes[i] = decoded.charCodeAt(i);
console.log(JSON.parse(new TextDecoder().decode(bytes)));

11. Communication Sequence Diagram

This diagram shows the exact sequence of calls between the CGLinkHandler and your UI dApp:

12. Real-World Use Cases

Theory is great, but let’s see GLinks in action. Here are practical examples showing how GLinks solve real problems and create better user experiences across GRIDNET OS.

Payment Request Links

Perhaps the most compelling use case: imagine sending someone a link that opens their wallet with everything pre-filled—recipient, amount, even a memo. No manual typing, no copy-paste errors:

// Generate payment request for an invoice
function generateInvoiceLink(recipientDomain, amountGNC, invoiceId) {
return CGLink.create(
CGLink.PackageIDs.WALLET,
'send',
1, // PREFILL_SEND action
{
address: recipientDomain,
amount: amountGNC.toString(),
memo: `Invoice #${invoiceId}`
}
);
}
// Example: Generate link for $50 payment
const paymentLink = generateInvoiceLink('merchant.grid', 50, 'INV-2025-001');
// Can be embedded in email, QR code, or web page

Transaction Verification Links

Share links to verify transactions on the blockchain explorer:

// After sending a transaction, generate verification link
async function sendAndGetVerificationLink(recipient, amount) {
// Send the transaction
const txResult = await this.vmContext.sendTransaction(recipient, amount);
if (txResult.success) {
// Generate explorer link for recipient to verify
const verifyLink = CGLink.create(
CGLink.PackageIDs.EXPLORER,
'transactions',
2, // VIEW_TRANSACTION
{ txId: txResult.transactionId }
);
return {
txId: txResult.transactionId,
verificationLink: verifyLink
};
}
}

Domain Profile Links

// Create shareable profile link for a domain
const profileLink = CGLink.create(
CGLink.PackageIDs.EXPLORER,
'search',
3, // VIEW_DOMAIN
{ domain: 'alice.grid' }
);
// Use in social media bio, email signature, etc.
// "View my GRIDNET profile: [GLink URL]"

13. Troubleshooting Guide

GLink issues usually fall into a few common categories: timing problems, missing handler calls, or race conditions with UI rendering. Here are the most frequent problems and their solutions, gathered from real debugging sessions:

14. Security Considerations

GLinks are a powerful feature, but with power comes responsibility. Remember: the data in a GLink ultimately comes from an external source—a URL that could have been crafted by anyone. A malicious actor could create a GLink with unexpected values, attempting to trick users or exploit vulnerabilities in your dApp.

Example: Secure GLink Processing

processGLink(glinkData) {
const glinkHandler = CGLinkHandler.getInstance();
try {
// Validate required fields
if (!glinkData || typeof glinkData !== 'object') {
throw new Error('Invalid GLink data format');
}
const { action, data } = glinkData;
// Validate action is a known integer
if (action !== null && (!Number.isInteger(action) || action < 1 || action > 10)) {
throw new Error('Invalid action ID');
}
// Validate specific data fields based on action
if (action === 1) { // PREFILL_SEND
if (!data?.address || typeof data.address !== 'string') {
throw new Error('Invalid recipient address');
}
if (data.address.length > 64) { // Max domain length
throw new Error('Address too long');
}
if (data.amount) {
const amount = parseFloat(data.amount);
if (isNaN(amount) || amount <= 0) {
throw new Error('Invalid amount');
}
}
}
// Accept and process
glinkHandler.acceptGLink('Validated, processing...');
this.executeValidatedAction(action, data);
glinkHandler.confirmGLinkProcessed('Success');
} catch (error) {
console.error('[Security] GLink validation failed:', error);
glinkHandler.rejectGLink(error.message);
}
}
